- detail
- parameters
1, the highest rated pressure 57 mpa
2, the biggest rail pulling force of 2 x 450 kn
3, the range of working oil cylinder: ≥500 mm
4, the two pull rod center distance :535 mm
5, locking oblique iron grip on both sides of rail head
6, oil pump models honda gxv160 internal combustion
power: 3.05 kw
flow ：≥3 l/min
7,weight: 310 kg
8, the internal combustion pump station quality :91 kg (excepting tubing)
spec
1, the highest rated pressure 57 mpa 2, the biggest rail pulling force of 2 x 450 kn 3, the range of working oil cylinder: ≥500 mm 4, the two pull rod center distance :535 mm 5, locking oblique iron g
model
yls-900i-rail-tensor
