1, power:

(1) sf190 type diesel engine

work rate 7 kw

revolution of 2300 r/min

work rate 6.6 kw

revolution of 3600 r/min

2, hydraulic system working pressure 5 ~ 6 mpa

3, vibration frequency 66.7 hz

4, vibration force: 22 kn

5, inserted under the maximum force 16 kn

6, clamp strength 6.5 kn x 2

7 inserted depth of 110 mm ± 10 mm (sleeper bottom below)

8, production efficiency was 270 root / (group • hours)

9, host net weight:

water-cooled diesel engine: 455 kg

10, physical size:

water-cooled diesel engine: 1300 mm * 750 mm * 1600 mm

gasoline engine: 1390 mm * 750 mm * 1600 mm
